Cardiac Ultrasound Machine Trolley Color Doppler

Product Description

Cardiac Ultrasound Machine Trolley Color Doppler
Technical Parameters:

Monitor	19" high-resolution LCD color monitor
Gray scale	256
Scanning lines	≥256
Dynamic Range	30dB-75dB
Maximum frame rate	≥65/s
Pseudo-color display	11
Cine loop	≥100 frame
Image memory	≥160G, format BMP/JPG/DCM/TIF
Partial enlarged	≥ 4 times
TGC	≥8
Image mode	B, BB, 4B, B+M , M, PWD, PwrD, CD, CWD, DirPwr, B+C+D.
Image processing	8 frame-related, 6 related to six-speed lines
Noise Reduction	32 adjustable
Wall filter	40-500 adjustable
Scan speed	8 adjustable
Gain	20dB-48dB , grading adjustable
Sample volume	0.5-10mm adjustable range 20
Pulse repetition frequency	0.5-2khz , 6 adjustable

Note: body mark and character note, body mark: ≥100
Image flip : up and down , left and right , image rotation ( 2B, 4B mode rotated 90 ° ) , black and white
DICOM3.0 interface with network remote assistance software
Sampling frame size, position and color : support B / color consistent width adjustable
Support synchronous updates automatically trace and spectral inversion
Baseline position, spectrum volume and correction angle : adjustable
Blood flow measurement velocity:
a) Maximum blood flow velocity measurement : pulse doppler > 2m/s
b) Lowest measured blood flow velocity : <2mm /s (non-noise signals)
Port and holder: 4 activated probe ports and holders, 1 Gel heater holder
Input / Output Interface : USB2.0 , LAN , VGA , RS232 , Video, DICOM3.0, foot switch, XGA, DVD burner
Machine dimension (mm): 920*550*1450

Measurement:
Mode B (2D) measurement
a) General measurement: distance, perimeter, area, volume, distance narrower radio, area stenosis ratio.
b) Gynecological measurement: uterine size and volume, cervix size and volume, right/left ovary size and volume, endometrial thickness, right/left follicle volume.
M mode measurements: distance, heart rate.
Doppler measurements: General measurement: systolic and end-diastolic velocity, peak flow, time, blood flow, pulse index and heart rate.

Standard Configuration:
Scanner Body: 1pc
3.5Mhz Convex Probe: 1pc
Charger with a Set of Wires: 1set
Bottle of USG gel: 1pc
User Manual: 1pc
USB disk: 1pc

Optional:
Micro-convex probe
Phased array probe
Trans-virginal probe
Linear probe
4D Volume probe
Printer
Guided probe holder

FAQ
1.Are you manufacture?
Yes,we have our own team,we provide you non-stop service.

2. What is your Packing details?
A: 1.Wooden case or carton package,standard export packages
2.All of the productions are inspected carfully by QC before delivery.

3.What is your Delivery time?
A: Usually, we make merchandise inventory, if we have the products in stock,the delivery time is1-3 days after receiving the payment
B: If we don't have the products in stock, we will arrange the production right now, the delivery time will be 5-7days,It depends on the quantity of order

4.: What is your Min.order?
A: 1set

The Exhibition
Cardiac Ultrasound Machine Trolley Color Doppler
