Fully-Automatic Blood Cell Analyzer/Auto Hematology Analyzer
Fully-automatic Blood Cell Analyzer/Auto Hematology AnalyzerModel: MCL-3800 Features :1. Fully digitized process of signals from blood cell, mature design of fluid path to ensure the reliability of measurement.2. Advanced floating threshold combined with perfect abnormal blood samp......
Send Inquiry
Product Description
Model: MCL-3800
Features :
1. Fully digitized process of signals from blood cell, mature design of fluid path to ensure the reliability of measurement.
2. Advanced floating threshold combined with perfect abnormal blood sample expert recognition system
3. Independent hemoglobin detecting system, unique volume metering pipe direct quantify technology; the interference source can be eliminated and precision can be increased.
4. Particle wizard technology: cells'straight-line motion produce pulse to ensure the accuracy of WBC,RBC,PLT counting
5. Bi-directional stereoscopic rotational flow technology: avoiding fluid interfering PLT counting
6. 3-part white blood cell differential
7. Dual-channel, 60 T/H
8. Brand-new highly accurate trace blood treating technology
9. Impedance technology, Cyanide methemoglobin method and non-cyanide SFT method
10. 8.4 inches TFT touchscreen
Parameters:
| Items Tested | RBC, MCV, HCT , RDW-SD, RDW-CV; HGB, MCH, MCHC ; PLT, MPV , PDW , PCT ; WBC, LYM#, LYM% ,MID# ,MID% ,GRA# ,DRA% ,P-LCR ; (WBC,RBC,PLT Histogram included) |
| Working Method: | blood cell counting: Impedance Method; HGB Test: HGB-546nm Colorimetric Method |
| Clinical function : | 3-part differential, 23 parameters |
| Throughput: | 60T/H |
| linearity range | RBC 1.00~9.90X10/L HGB 25~400g/L WBC 0.5~99.0X10/L PLT 50~999X10/L |
| Precision: | RBC <= 2% HGB <= 2% WBC <= 2% PLT <= 4% MCV <= 1% |
| Sample volume: | venous blood 9.7 μL peripheral blood 20 μL |
| Dilution Rate: | WBC/HGB 1/400; RBC/PLT 1/40000 |
| Operation Interface: | 8.4 inches TFT touchscreen, English operation interface |
| Calibration: | Automatic calibration and manual calibration |
| Quality control software | Multi-level QC summary, X, SD and CV auto-summary,auto-calculate average value of MCV, MCH, MCHC, and store QC results |
| Data storage | >30000results of sample,including 3 histograms |
| Reporting system: | built-in thermal high-speed printer, EPSON LQ-300K+2 printer connectable |
| data interface | Two USB interface, one RS-232 interface, one printer interface |
| Information edition | Patient information can be imported,including name of patient,department,inspector,etc. |
| Dimension | 330mm X 420mm X 400mm |
| Weight | 15kg |
Other models of Auto Hematology Analyzer:
MCL-880
MCL-7501
