China IN-BAE7 ICEN high quality cost-effective BioS1no Flow Cytometry

Product Description

IN-BAE7 ICEN high quality cost-effective BioS1no Flow Cytometry

Product Description:

Dimension:470mm*460mm*290mm

Weight 25KG

Power Supply AC 220V,50Hz

Power Rate Input:90VA

https://youtu.be/Pal-ePKdTRU

Clinical Application:

1. Analysis and absolute count of lymphocyte subsets:T/B/NK;

2. HLA-B27 detection: ankylosing spondylitis;

3. Blood disease/lymphoma immunophenotyping;

4. Functional lymphocyte subsets analysis: Th1, Treg;

5. Count of CD34 hemopoietic stem cell;

6. PNH auxiliary diagnosis:CD55 , CD59 , FLARE,CD14 , CD15;

7. Multiple myeloma;

8. Platelets: count and immunophenotype analysis of platelets;

9. Count of Reticulocytes;

10. Minor residual disease monitor of acute leukemia;

11. DNA ploidy analysis;

12. Drug efficacy monitor.

Application	Reagents	Clinical Office
Lymphocyte Subset T		Lab,Infection,Oncology, Rheumatology,pediatrics,Blood
Lymphocyte Subset T/B/NK		Lab,Infection,Oncology, Rheumatology,pediatrics,Blood
CD4+T absolute count		CDC, Infection
Cytokine Th1/Th2/Th17		Oncology, Rheumatology,Infection, Respiration, Organ Transplant
HLA-B27		Orthopedics, Rheumatology
Sperm DFI test	Acridine Orange Dye	Reproductive center, Infertility

Item	Parameters
Laser	488nm solid
Detector	FSC,SSC,FL1-FL5
Fluorescence Channel	FL1:525/50(FITC) FL2:585/40(PE) FL3:630/30(PE-Texas Red/ECD/PI) FL4:697/60(PerCP/PE-Cy5/PE-Cy5.5) FL5:780/60(PE-Cy7)
Fluorescence sensitivity	FITC ≤ 100 MESF;PE ≤ 50 MESF
Fluorescence linearity	≥ 0.99
FSC sensitivity	≤ 1μm
Test particle size	0.5-50μm
Carry Over	≤ 0.5%
Instrument CV	FSC and all FL channel CV less than 2%
FSC and SSC CV	Can separate red blood cells and platelet, can separate white blood cells into 3 groups
Test speed	≥38000 cells/s
Minimum Sample Vol	90μL
Measure Range	Maximum Support 10⁷
Threshold	Double threshold, minimum cells fraction
Fluorescence compensation	Support auto online compensation, offline compensation and visualized compensation
Item Template	Support Item template, acquisition condition/ fluorescence compensation 1-click use
Intake method	Manual intake Rotary Wheel auto-sampling with auto- mixing function:32tests/wheel,
Liquid storage station	sheath bottle, waste bottle, shutdown liquid bottle 2L cleaning liquid bottle 0.5L
Software	English/Chinese
PC	Dell(CPU i5/8G DDR4/1T hard disk)+Dell 27 inches monitor
Size/ Weight	500mm605mm305mm(LWH),35KG

How to buy your products ?Do you have distributor in our country?

You can buy the products from our company directly.Normally the procedure is:Sign the contact ,payment byT/T, contact the shipping company to delivery the goods to your country.

What is the warranty?

The free warranty is one year from the day of Commissioning qualified.

Can we visit your country ?

Of course,we will prepare for everything in advance if it is necessary .Generally,it is require that customers must have build agency relationship or business relationship with our company.

How long is the validity of quotation?

Generally,our price is valid within one month from the date of quotation .The price will be adjusted appropriately according to the price fluctuation of raw material and changes in market .
